Fiber Reinforced Cement Composite Board

Core Composition and Process

 Panel: High-density, asbestos-free fiber-reinforced cement board, high strength, weather resistance, and compatible with various finishes.

 Core Layer (Composite): Rock wool/polystyrene/polyurethane, etc., achieving integrated thermal insulation, sound insulation, and lightweight design.

 Process: Vacuum dehydration → High-pressure molding → High-temperature steam curing → Interface lamination → Cutting/Surface treatment

 Environmentally friendly: Asbestos-free, formaldehyde-free, VOC-free, radioactivity complies with GB 6566, suitable for hospitals, schools, and residences.

Core Performance Advantages

1. Fire Safety (Core Selling Point)

 Class A non-combustible combustion performance, non-combustible at high temperatures, smokeless and non-dripping

 Fire resistance limit up to 0.5–2 hours, meeting the fire protection requirements of public buildings, factories, pipe shafts, tunnels, etc.

2. Lightweight and High Strength

 Low surface density, reducing structural load, suitable for high-rise buildings and old building renovations

 Flexural strength 15–30 MPa, impact-resistant, crack-resistant, wind-pressure resistant, stable for exterior wall and roof systems

 Low temperature and humidity deformation rate, no blistering, cracking, or deformation after long-term use

3. Waterproof, Moisture-proof, and Mildew-proof

 Low water absorption rate and low moisture expansion rate, stable in kitchens, bathrooms, basements, and high-humidity coastal environments

 Does not breed mold or rot, superior to traditional wood and gypsum boards

4. Durable and Weather-resistant

 Resistant to freeze-thaw cycles, acids and alkalis, and salt spray, with a service life of 50 years+

 Excellent outdoor weather resistance, suitable for exterior wall cladding, curtain wall lining, and roof underlayment

5. Thermal insulation, sound insulation, and easy construction

 The composite structure has a low thermal conductivity, resulting in energy savings and reduced consumption.

 Weighted sound insulation can reach over 45dB, enhancing spatial privacy.

 It can be cut, drilled, nailed, and glued; dry construction method, short construction period, and labor savings.

Standard Specifications (Customizable)

 Standard Size: 1220mm × 2440mm

 Thickness: 4mm–30mm (Partition walls 6–12mm; Exterior walls/load-bearing 12–24mm; Composite panels 50–200mm)

 Density: 1.3–2.0g/cm³ (High-density versions suitable for exterior walls and load-bearing applications)

 Finishes: Plain board / Sanded / Fluorocarbon coating / Stone paint / Wood grain / Stone grain, etc.

Typical Application Scenarios

1. Interior Walls/Partitions: Office buildings, hotels, residences, hospitals, schools, shopping mall partitions; fire compartments, pipe shaft sealing, computer room partitions

2. Exterior Wall Systems: Exterior wall cladding, curtain wall lining, integrated thermal insulation exterior walls, renovation of old building exterior walls

3. Ceilings and Roofs: Fireproof ceilings, tunnel ceilings, roof linings, attic floors

4. Special Scenarios: Factory workshops, warehouses, substations, data centers, clean rooms, ships, and temporary buildings

Product Value Summary

 Safety: Class A fireproof, asbestos-free, formaldehyde-free, compliant with all application scenarios

 Durability: Waterproof, moisture-proof, crack-resistant, weather-resistant, long-term maintenance-free

 Efficiency: Lightweight and easy to install, dry construction method, cost reduction and speed increase

 Aesthetics: Diverse finishes, suitable for modern architectural minimalist/high-end styles

 Green: Inorganic, environmentally friendly, recyclable, meets green building and prefabricated construction requirements
